Tc40L Slant Bed CNC Lathe with Power Turret Turning and Milling Machine

Basic Info

Model NO.	TC40Lx500mm
After-sales Service	Yes
Warranty	12 Months
Controller	Siemens808d16 Ver
Spindle Motor	Siemens Spindle Servo Motor 11kw
Distance Between Centers	450mm
Max. Swing Over Bed	Φ440mm
Max. Swing Over Cross Slide	Φ180mm
Spindle Seed	4000rpm
Spindle Bore	66mm ( 50mm After Hydraulic Chuck )
Spindle Nose	A2-6
Hydraulic Chuck	200mm
Power Turret	Pragatti - 12 Station (20X20mm)
Turret Power Tool	1 Ath30-Er25, 1rth30-Er25
Tailstock	Hydraulic Tailstock
Transport Package	Wooden Case
Specification	3.00*2.22*2.28 M
Trademark	ZINO
Origin	Jiangsu Province
HS Code	8458110090
Production Capacity	200 Pieces / Year

Product Description

FEATURES

* 4 shafts linkage Turning and Milling CNC Lathe Machine

* One piece base and bed wholly ensures high rigidity of the machine

* Taiwan brand high precision linear guide ensure positioning accuracy more stable

* Adaptable to various control systems such as GSK, Siemens, Fanuc

MODEL	CK40L
Controller	Siemens 808DA ver.16
Distance between centers	500mm	750mm
Max. swing over bed	Φ450mm
Max. swing over cross slide	Φ180mm
Spindle
Max. Spindle speed	4000rpm
Spindle bore	Φ 66mm (50mm after hydraulic chuck)
Spindle nose	A2-6
Stroke & Feeding Speed
X axis travel	240 mm
Z axis travel	500 mm	750mm
X/Z axis Rapid traverse	15 / 15 m/min
Chuck
Type	Hollow hydraulic chuck
Chuck Size	200mm
Turret
Type	12 pos. Power turretPragatti 1 ATH30-ER25,1RTH30-ER25
Tool station number	12
Tool holder	20x20mm
Tailstock Sleeve
Type	Hydraulic sleeves
External diameter	Φ75 mm
Max. travel	80 mm
Taper of bore	MT4
Motor
Spindle motor type	SIEMENS Sevro Spindle motor
Spindle motor power	SIEMENS 11KW
X/Z Axis motor type	Siemens Incremental motor
X/Z Axis motor power	11B N/M	11 N/M
Power turret tool motor	Siemens 11 N/M
Coolant pump power	370W
Machine Dimensions
Type of guideway & screw	Taiwan linear guideway & screw
Overall dimension(L×W×H)	2800 x1800x1800mm	3150 x1800x1800mm
Packing size(L×W×H)	3000 x2000x2000mm	3450 x2000x2000mm
Net/Gross weight	3100/3400kg	3300/3600kg
